"id": "7ff25fc2.175c6",
"type": "tab",
"label": "Systemstatus",
"disabled": false,
"info": ""
},
{
"id": "5fb1954f.98290c",
"type": "ioBroker in",
"z": "7ff25fc2.175c6",
"name": "memory_available",
"topic": "rpi2.0.memory.memory_available",
"payloadType": "value",
"onlyack": "",
"func": "rbe",
"gap": "",
"x": 110,
"y": 40,
"wires": [
[
"9a2c81c4.56499"
]
]
},
{
"id": "24651264.fc27ce",
"type": "ui_text",
"z": "7ff25fc2.175c6",
"group": "c0fd0792.4101d8",
"order": 1,
"width": 0,
"height": 0,
"name": "",
"label": "freier RAM",
"format": "{{msg.payload}}",
"layout": "row-spread",
"x": 730,
"y": 40,
"wires": []
},
{
"id": "9a2c81c4.56499",
"type": "ioBroker get",
"z": "7ff25fc2.175c6",
"name": "memory_total",
"topic": "rpi2.0.memory.memory_total",
"attrname": "total",
"payloadType": "value",
"x": 320,
"y": 40,
"wires": [
[
"f9de488f.352a08"
]
]
},
{
"id": "f9de488f.352a08",
"type": "function",
"z": "7ff25fc2.175c6",
"name": "zusammensetzen",
"func": "var available = msg.payload;\nvar total = msg.total;\n\nvar availableRound = Math.round(available * 10) / 10;\nvar totalRound = Math.round(total * 10) / 10;\n\nmsg.payload = availableRound + ' MB / ' + totalRound + ' MB';\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 530,
"y": 40,
"wires": [
[
"24651264.fc27ce"
]
]
},
{
"id": "4407ac50.a6a1d4",
"type": "ui_text",
"z": "7ff25fc2.175c6",
"group": "c0fd0792.4101d8",
"order": 3,
"width": 0,
"height": 0,
"name": "",
"label": "Betriebszeit",
"format": "{{msg.payload}}",
"layout": "row-spread",
"x": 730,
"y": 100,
"wires": []
},
{
"id": "b3d7501c.69fcf",
"type": "ioBroker in",
"z": "7ff25fc2.175c6",
"name": "memory_available",
"topic": "rpi2.0.uptime.uptime",
"payloadType": "value",
"onlyack": "",
"func": "rbe",
"gap": "",
"x": 110,
"y": 100,
"wires": [
[
"a700f6a1.f9e168"
]
]
},
{
"id": "a700f6a1.f9e168",
"type": "function",
"z": "7ff25fc2.175c6",
"name": "berechnen",
"func": "var x = msg.payload;\nvar tag,std,min,sek; \n\nfunction umwandeln(x)\n{\nvar c=60;\nvar d=24;\n {\n sek = x;\n min = Math.floor(sek/c); \n sek = sek % c;\n std = Math.floor(min/c);\n min = min % c;\n tag = Math.floor(std/d);\n std = std % d;\n }\n}\n\numwandeln(x)\n\nsek = Math.round(sek * 10);\n\nmsg.tag = tag;\nmsg.std = std;\nmsg.min = min;\nmsg.sek = sek;\n\nmsg.payload = tag + ' Tage, ' + std + ' Stunden, ' + min + ' Minuten';\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 510,
"y": 100,
"wires": [
[
"4407ac50.a6a1d4"
]
]
},
{
"id": "7f8416d7.27f038",
"type": "ioBroker in",
"z": "7ff25fc2.175c6",
"name": "ssd_used",
"topic": "rpi2.0.sdcard.sdcard_root_used",
"payloadType": "value",
"onlyack": "",
"func": "rbe",
"gap": "",
"x": 80,
"y": 160,
"wires": [
[
"7b588f48.3cae4"
]
]
},
{
"id": "7b588f48.3cae4",
"type": "ioBroker get",
"z": "7ff25fc2.175c6",
"name": "ssd_total",
"topic": "rpi2.0.sdcard.sdcard_root_total",
"attrname": "total",
"payloadType": "value",
"x": 240,
"y": 160,
"wires": [
[
"92fb0b2c.bc2688"
]
]
},
{
"id": "92fb0b2c.bc2688",
"type": "function",
"z": "7ff25fc2.175c6",
"name": "berechnen + zusammensetzen",
"func": "var used = msg.payload;\nvar total = msg.total;\n\nvar usedGB = used / 1024;\nvar totalGB = total / 1024;\n\nvar usedRoundGB = Math.round(usedGB * 10) / 10;\nvar totalRoundGB = Math.round(totalGB * 10) / 10;\n\nmsg.available = Math.round((totalRoundGB - usedRoundGB) * 10) / 10;\n\nmsg.payload = usedRoundGB + ' GB / ' + totalRoundGB + ' GB';\nreturn msg;",
"outputs": 1,
"noerr": 0,
"x": 490,
"y": 160,
"wires": [
[
"126325f8.6f47aa",
"280c6b51.ffff14"
]
]
},
{
"id": "126325f8.6f47aa",
"type": "ui_text",
"z": "7ff25fc2.175c6",
"group": "c0fd0792.4101d8",
"order": 4,
"width": 0,
"height": 0,
"name": "",
"label": "Speicherplatz genutzt",
"format": "{{msg.payload}}",
"layout": "row-spread",
"x": 760,
"y": 160,
"wires": []
},
{
"id": "280c6b51.ffff14",
"type": "ui_text",
"z": "7ff25fc2.175c6",
"group": "c0fd0792.4101d8",
"order": 5,
"width": 0,
"height": 0,
"name": "",
"label": "Speicherplatz frei",
"format": "{{msg.available}} GB",
"layout": "row-spread",
"x": 750,
"y": 200,
"wires": []
},
{
"id": "772e289b.0bc7d8",
"type": "ui_text",
"z": "7ff25fc2.175c6",
"group": "c0fd0792.4101d8",
"order": 2,
"width": 0,
"height": 0,
"name": "",
"label": "Temperatur",
"format": "{{msg.payload}} °C",
"layout": "row-spread",
"x": 730,
"y": 260,
"wires": []
},
{
"id": "7e2f0642.9ca4f8",
"type": "ioBroker in",
"z": "7ff25fc2.175c6",
"name": "soc_temp",
"topic": "rpi2.0.temperature.soc_temp",
"payloadType": "value",
"onlyack": "",
"func": "rbe",
"gap": "",
"x": 80,
"y": 260,
"wires": [
[
"772e289b.0bc7d8"
]
]
},
{
"id": "c0fd0792.4101d8",
"type": "ui_group",
"z": "",
"name": "System",
"tab": "d9adc03f.8cae1",
"disp": true,
"width": "8",
"collapse": false
},
{
"id": "d9adc03f.8cae1",
"type": "ui_tab",
"z": "",
"name": "Home",
"icon": "dashboard",
"order": 1
}
]
